KPM Minimoto
1 / 5
| Technical Parameter Data Sheet | ||||||||
| No. | Model No. | Dimensions(mm) | Stroke(mm) | Slider material | Voltage(V) | Current(mA) | Resistance(Ω) | Output Torque(gf.cm) |
| 1 | 07-005-002 | Φ6x(5.9+3.95) | / | / | 3.3 | 165 | 20 | / |
| 2 | 07-005-003 | Φ6x(5.9+3.95) | / | / | 3.3 | 165 | 17.5 | / |
| 3 | 07-005-004 | Φ6x(5.9+3.95) | / | / | 3.3 | 275 | 12 | 2.00 |
| 4 | 07-005-005 | Φ6x(9.1+11.4) | 6.8 | Plastic | 3.3 | 110 | 30 | 0.06 |
| 5 | 07-005-006 | Φ6xL(8+4.8) | / | / | 4.8 | 180 | 26.5 | 1.60 |
| 6 | 07-005-007 | Φ6x(7.7+5.1) | / | / | 4.8 | 180 | 26.5 | 1.60 |
| 7 | 07-005-011 | Φ6x(4.3+2.9) | / | / | 3.3 | 110 | 30 | 0.06 |
| 8 | 08-005-001 | Φ6x(7.8+4.5) | 10.7 | / | 5.0 | 300 | 15 | 1.00 |
| 9 | 07-005-027 | Φ8x(8.82+23) | 16 | Plastic | 3.3 | 160 | 20 | 80.00 |
| 10 | 07-005-032 | Φ8x(8.5+4.2) | / | / | 3.3 | 165 | 20 | 1.50 |
| 11 | 07-005-033 | Φ8x(8.82+18.6) | 17 | / | 3.3 | 160 | 20 | 0.25 |
| 12 | 07-005-034 | Φ8x(8.82+15.75) | 13.35 | / | 5.0 | 100 | 50 | 0.23 |
| 13 | 07-005-035 | Φ8x(8.5+4.1) | / | / | 3.3 | 165 | 20 | 1.50 |
| 14 | 08-005-011 | Φ8.3x(10.1+22.5) | 19.4 | Copper | 3.0 | 500 | 6 | 20.00 |
| 15 | 08-005-012 | Φ8x(+) | / | / | 3.0 | 500 | 6 | 20.00 |
| 16 | 08-005-013 | Φ8.3x(9+5.7) | / | / | 4.8 | 220 | 23 | 3.00 |
| 17 | 08-005-014 | Φ8.3x(9+14) | 11.5 | / | 5.0 | 300 | 16.3 | 30.00 |
| 18 | 08-005-015 | Φ8.3x(9+4) | / | / | 3.3 | 500 | 6 | 2.50 |
| 19 | 07-005-041 | Φ10x(10.62+37.6) | 36.6 | / | 5.0 | 90 | 55 | 0.30 |
| 20 | 07-005-042 | Φ10x(10.62+37.6) | 34.4 | Copper | 5.0 | 90 | 55 | 0.30 |
| 21 | 07-005-043 | Φ10x(+) | / | / | 5.0 | 160 | 31 | 5.00 |
| 22 | 07-005-044 | Φ10x(+) | / | / | 5.0 | 160 | 31 | 7.00 |
| 23 | 07-005-045 | Φ10x(9.62+38.6) | 33.8 | Copper | 5.0 | 300 | 15 | 6.50 |
| 24 | 07-005-046 | Φ10x(9.3+19) | / | / | 5.0 | 250 | 20 | 15.00 |
| 25 | 07-005-047 | Φ10x(9.8+2.4) | / | / | 3.3 | 66 | 15 | 4.00 |
| 26 | 07-005-048 | Φ10x(8.8+5.1) | / | / | 5.0 | 300 | 15 | 5.00 |
| 27 | 07-005-049 | Φ10x(9.3+2.9) | / | / | 3.3 | 66 | 15 | 4.00 |
| 28 | 08-005-021 | Φ10x(10+56.5) | 50.5 | Copper | 5.0 | 270 | 18 | 6.00 |
| 29 | 08-005-022 | Φ10x(10+70) | 65 | Copper | 5.0 | 270 | 18 | 6.00 |
| 30 | 08-005-024 | Φ10x(9+14.5) | / | / | 5.0 | 200 | 25 | 150.00 |
| 31 | 08-005-025 | Φ10x(10.5+9) | / | / | 5.0 | 128 | 20 | 500.00 |
| 32 | 08-005-026 | Φ10x(10.8+31) | 23.9 | Plastic | 5.0 | 330 | 15 | 5.00 |
| 33 | 08-005-031 | Φ10.2x(10.75+11.4) | 5.4 | Plastic | 5.0 | 330 | 15 | 9.00 |
| 34 | 08-005-032 | Φ10.2x(10.75+11.4) | 5.4 | Plastic | 5.0 | 330 | 15 | 9.00 |
| 35 | 08-005-033 | Φ10x(10.6+38.6) | 35.1 | Copper | 5.0 | 330 | 15 | 7.00 |
| 36 | 08-005-035 | Φ10x(10.72+18.55) | 15.5 | Copper | 5.0 | 128 | 39 | 4.00 |
| 37 | 08-005-036 | Φ10x(10.75+18.6) | 11.8 | Plastic | 5.0 | 330 | 15 | 9.00 |
| 38 | 08-005-037 | Φ10x(10.75+14.7) | 7 | Plastic | 5.0 | 400 | 15 | 9.00 |
| 39 | 08-005-038 | Φ10x(10.75+18.6) | 11.8 | Plastic | 5.0 | 330 | 15 | 9.00 |
| 40 | 08-005-039 | Φ10x(10.75+12.6) | 5.4 | Plastic | 5.0 | 330 | 15 | 9.00 |
| 41 | 07-005-060 | Φ15x(10.8+59) | / | / | 12.0 | 400 | 31 | 180.00 |
| 42 | 07-005-061 | Φ15x(12.9+36.5) | 26.7 | Copper | 6.0 | 300 | 15 | 200.00 |
| 43 | 07-005-062 | Φ15x(12.9+46.5) | 12.9 | Copper | 6.0 | 300 | 15 | 200.00 |
| 44 | 07-005-063 | Φ15x(10.8+12) | / | / | 12.0 | 760 | 31 | 720.00 |
| 45 | 07-005-064 | Φ15x(12.9+46.5) | 37.5 | Copper | 12.0 | 760 | 31 | 720.00 |
| 46 | 07-005-079 | Φ15x(10.8+12) | / | / | 12.0 | 760 | 31 | 720.00 |
| 47 | 08-005-041 | Φ15x(11+16.5) | / | / | 3.0 | 200 | 15 | 6.00 |
| 48 | 08-005-042 | Φ15x(10.9+30) | 19.7 | Copper | 6.0 | 400 | 15 | 200.00 |
| 49 | 08-005-043 | Φ15x(10.9+30) | 20 | Plastic | 6.0 | 400 | 15 | 200.00 |
| 50 | 08-005-046 | Φ15x(21+13) | / | / | 12.0 | 200 | 118 | 1700.00 |
| 51 | 08-005-047 | Φ15x(10.9+25) | 11.8 | Copper | 6.0 | 400 | 15 | 200.00 |
| 52 | 08-005-048 | Φ15x(11.3+30) | 17.5 | Copper | 12.0 | 200 | 31 | 700.00 |
| 53 | 07-005-082 | Φ20x(21+46.1) | 34.2 | Copper | 12.0 | 800 | 15 | 1800.00 |
| 54 | 07-005-083 | Φ20x(21+66.9) | 55.9 | Copper | 12.0 | 800 | 15 | 1800.00 |
| 55 | 07-005-084 | Φ20x(18.4+4) | / | / | 12.0 | 300 | 40 | 20.00 |
| 56 | 08-005-061 | Φ20x(20.1+34.9) | 22 | Copper | 12.0 | 770 | 15.6 | 1200.00 |
| 57 | 08-005-062 | Φ20x(20.1+34.9) | 22 | Copper | 12.0 | 770 | 15.6 | 1200.00 |
| 58 | 08-005-063 | Φ20x(20.1+47.9) | 35 | Copper | 12.0 | 600 | 20 | 1000.00 |
| 59 | 08-005-064 | Φ20x(18.4+4.3) | / | / | 12.0 | 600 | 20 | 32.00 |
| 60 | 08-005-065 | Φ20x(37.4+10.5) | / | / | 12.0 | 600 | 20 | 2000.00 |
| 61 | 08-005-066 | Φ20x(35.9+10.5) | / | / | 12.0 | 200 | 60 | 500.00 |
| 62 | 08-005-101 | Φ20x(15.5+19) | / | / | 12.0 | 200 | 60 | 1000.00 |
