Environmental Test Conditions
| Item |
Environmental Condition |
| Temperature | 20±2ºC |
| Humidity | 60±5% RH |
| Motor Position | Shaft Horizontal |
| Power Supply | DC 2.5V±2% |
NOTE: All data shall be based on measurement under temperature 25±3ºC and humidity 60±7% RH. Range of temperature 5~35ºC and humidity 45~85%RH is acceptable if there is no doubt about judgment.
❓
Frequently Asked Questions
Q1: What is the rated voltage for this vibration motor?
The rated voltage is 2.5V DC, with an operating range of 2.0V to 2.5V DC.
Q2: What is the expected mechanical life of the motor?
The motor is designed for a mechanical life of approximately 100,000 cycles under no-load conditions.
Q3: Are there specific storage requirements?
It should be stored in an environment between -40ºC to 80ºC with humidity ≤90%RH.
Q4: Can I request samples before placing a bulk order?
Yes, we provide free samples for your testing. Shipping for samples typically takes 3-7 days via international couriers.
Q5: Is this product compliant with international standards?
Yes, our products are compliant with RoHS standards and have received CE certification.
Q6: What is the typical vibration strength of this motor?
The vibration strength is ≥1.0G when the motor is fixed at a rated voltage of DC 3.0V.
